Cisco 3945 Slot Numbering

Enabling Enterprise Networks at the Branch

Cisco 3945 Slot Numbering Chart

(5) AUX port (11) Service module slots (6) SFP 1 and SFP 2 (2, top) Modularity Features Table 2 shows modules for this router. Models Description C3900-SPE150/K9 Cisco Services Performance Engine 150 for Cisco 3945 ISR. (It's a configured item in the CISCO3945/K9.) SM-ES3G-16-P. . Three integrated EHWIC slots on the Cisco 3945E and Cisco 3925E or four integrated EHWIC slots on the Cisco 3945 and Cisco 3925 allow for flexible configurations. Each HWIC slot offers high-data-throughput capability: Up to 1.6-Gbps aggregate toward the router processor. Up to 2-Gbps aggregate to other module slots over the MGF.

The Cisco 3945 Integrated Services Router (ISR) delivers highly secure data, voice, video, and application services to the small office. Key features include:

  1. Let's say I need to find maximum number of PRIs I can connect on a C3945. I see that I could buy for example (4) VWIC3-4MFT-T1/E1. The C3945 comes with (4) EHWICs where such VWIC3-4MFT-T1/E1 cards can be inserted. Since each VWIC3 has (4) ports each, that would be total of 16 PRIs.
  2. 88probet is a leading Live Cisco 3945e Slot Numbering Casino Online and betting agent in Southeast Asia, Cisco 3945e Slot Numbering with a variety of slot games, trustworthy live casinos, and daily updated sportsbook in a smooth platform and fair play environment that maximize your efficiency and results.

Cisco 3945 Slot Numbering Machine

Numbering

Cisco 3945 Slot Numbering Tool

  • Modular Services Performance Engine (SPE) 150, which can be upgraded for even higher performance as next-generation WAN environments evolve
  • 3 integrated 10/100/1000 Ethernet ports with 2 ports capable of RJ-45 or SFP connectivity
  • 4 service module slots
  • 4 Enhanced High-Speed WAN Interface Card slots
  • 4 onboard digital signal processor (DSP) slots
  • 1 Internal Services Module slot
  • Dual integrated power supplies
  • Fully integrated power distribution to modules supporting 802.3af Power over Ethernet
  • Security
    • Embedded hardware-accelerated VPN encryption for secure connectivity
    • Integrated threat control using Cisco IOS Firewall, Cisco IOS Zone-Based Firewall, Cisco IOS IPS, and Cisco IOS Content Filtering
    • Identity management using authentication, authorization, and accounting (AAA) and public key infrastructure
  • Unified Communications
    • High-density-packet voice DSP module, optimized for voice and video support
    • Standards-certified VoiceXML browser services
    • Cisco Unified Border Element capabilities for up to 1000 sessions
    • Cisco Unity Express voicemail support
    • Support for Cisco Communications Manager Express and Survivable Remote Site Telephony
